Browser extensions are powerful extensions that allow users to extend and customize their browsing in many ways, which is why Apple is now bringing Safari web browser extensions to its mobile devices. With iOS 15 and iPadOS 15, iPhone and iPad will have access to the web extensions in the Apple store.
For those of you who are curious to know how you can build and debug iOS safari extensions, you are on the right page.In this article, we will be looking at how to create new extensions, debugging along the way, as well as some best practices that you should keep in mind while working with iOS Safari extensions.
Now, let’s jump right in.
If you have these, you are all set to build the iOS Safari extension.
Ok, so how many ways are there to build a Safari extension?
Conversion and adding iOS support would not be in the scope of this blog post, but we will talk about it in a different post soon.
Now let’s get started with building a brand new extension.
We will be creating a small extension called “WikiColorChanger” that will allow us to change the background color of a Wikipedia page.
Open the XCode and select, “Create a new XCode Project.”
It will ask for the Extension Name and what Language you would like to use. Give it a name and choose your preferred language. I am keeping Swift.
It will now ask for the app location. Select the folder and then “Create.”
This will create a new project and it has all the basic setup you need, to make a multiplatform extension.
You get some shared folders that allow you to have the same code for iOS as well as macOS and some folders separately for iOS and macOS.
It will start indexing the app. Once it’s ready, you can run the app from the Start button at the top. Make sure the scheme is set to the iOS application.
You can select the devices you want to run the app on. Since I have no devices connected, I’m selecting a built-in simulator.
An extension is basically an app that the user has to install and has to enable through Safari settings.
Wait until the app runs in the simulator and shows a screen similar to the following.
Next, Go to settings > Safari > Extensions > WikiBackgroundChanger
You will see it is disabled, and at the bottom of the “permissions” section it will say, “You have not allowed this extension on any websites yet”.
Once you enable the extension, it will show a list of the websites that the extension is requesting permissions for.
Safari gives users the ability to choose the specific websites that are allowed to have the extension actively functional.
By default, an extension generated by XCode template requests example.com.
Allow it and visit “example.com” on the mobile Safari app.
There, on the tab bar, you can see a jigsaw puzzle-like icon.
This way, Safari will let the user know how many extensions have access on the current page.
Now, let’s see the popup of the extension for iOS Safari.
Click “AA” and you will see “WikiBackgroundChanger.”
If you click on it, you will see a card opening from the bottom with the “Hello World” message.
This is nothing but a popup of the extension for iOS Safari. However, on iPad, it will appear the same as on macOS Safari.
Now let’s start building the extension.
Firstly, the extension should have its content script running on the Wikipedia site to make the necessary changes.
Update the manifest.json file to provide what websites your extension would run on.
Update the matches property in content_scripts as below. This way, it will support both desktop and mobile websites.
Now, before we move any further, we need to know what are the DOM elements that need to be changed in order to change the color of the main section.
Now is the right time to introduce Web Inspector for iOS Safari.
Let’s check out how it works.
Enable Develop menu:
And you should see the Web Inspector Window.
Now that the Web Inspector is open, you can use it the same way as you would a Desktop Safari browser.
Please Note: manifest.json errors can be checked at Safari Settings > Extensions > Extension Page.
Upon inspection, you will come to know about the DOM elements whose color needs to be changed to change the background color. For me, those are body, #content, and table. infobox.
Do the following changes and rebuild the app again to see the changes, because changes will not take place until you rerun the app.
//Content.js
let color = '#FA96A7'; // Keeping pink as default on first page load
const changeColor = () => {
document.querySelector("body").style.background = color;
document.querySelector("#content").style.background = color
document.querySelector('table.infobox').style.background = color
}
browser.runtime.onMessage.addListener((request, sender, sendResponse) => {
if(request.color) {
color = request.color
changeColor()
}
});
changeColor();
//popup.html
<!DOCTYPE html>
<html>
<head>
<meta charset="UTF-8">
<link rel="stylesheet" href="popup.css">
<script type="module" src="popup.js"></script>
</head>
<body>
<h2>WikiBackgroundChanger</h2>
<span>Choose Background Color</span>
<div id="color-container">
</div>
</body>
</html>
//popup.js
const colors = [
{
name: "Pink",
code: '#FA96A7'
},{
name: "Orange",
code: '#F28500'
},{
name: "Yellow",
code: '#fc3'
},{
name: "Grey",
code: '#A2A9B1'
}]
const sendColor = async (color) => {
const [tab] = await browser.tabs.query({currentWindow: true, active: true})
chrome.tabs.sendMessage(tab.id, { color })
}
colors.forEach(color => {
const button = document.createElement('button')
button.style.background = color.code
button.innerText = color.name
document.querySelector('#color-container').appendChild(button)
button.addEventListener('click', e => {
sendColor(color.code)
})
})
Refresh the Wikipedia page and you will not see page color change right away as Wikipedia is newly added to the content_script and needs to be given permission by the user.
You don’t need to visit Settings again to do that, simply click “AA” > WikiBackgroundChanger > Allow as per convenience.
This will Open Popup and There you can see the updated popup and background Color getting changed with color buttons which you can use to change page color.
Click on them and you can see the Wikipedia page changing color.
But the Popup design doesn’t look quite good. Don’t worry, you can also inspect the popup page and change the design.
Desktop Safari > Develop > Simulator >Select one with popup.html and hovering over it should highlight the popup.
Make the following changes to Popup.css and rebuild the app to see the new popup page design.
//popup.css
:root {
color-scheme: light dark;
}
body {
padding: 10px;
font-family: system-ui;
text-align: center;
}
button {
width: 75px;
height: 75px;
border-radius: 10px;
color: black;
font-size: 14px;
}
#color-container {
display: flex;
justify-content: space-evenly;
margin-top: 15px;
}
Now it looks much better and there we have built a new iOS Safari Extension.
Let’s not forget the Desktop Extension which runs absolutely fine with no changes (Don’t forget to change the scheme from iOS to macOS while building the application. You may also need to Allow unsigned applications as before, in order to see the extension in the extensions list).
When working with multi-platform compatible Applications and extensions, you should follow some best practices, which include:
